# Computer Graphics <!-- .element: class="r-fit-text" --> Week 13 --- ## Screens and Pixels  <!-- .element: style="height:400px" --> -- ### Coordinates  <!-- .element: style="height:400px" --> -- ### Why Inverted? Computer coordinates are often inverted (y-axis pointing downwards) NOTES: - First graphics terminals used origin at the top-left corner of the screen due (largely) to the way CRT monitors scanned the image from top to bottom - Using a coordinate system with the y-axis pointing downwards makes it easier to **render text** correctly. -- ### Resolution Resolution is the number of pixels in each dimension Written as "w x h" or "w / h" ### Common Resolutions - 720p / HD: 1280×720 px - 1080p / FHD: 1920x1080 px - 1440p / QHD: 2560×1440 px - 2160p / UHD: 3840×2160 px - 4K: 4096×2160 px - 8K: 7680×4320 px NOTE: - HD = High Definition - FHD = Full HD - QHD = Quad HD - UHD = Ultra HD - Total number of pixels in 720p is 921,600 px while 1080p is 2,073,600 px - Total number of pixels in 4K is 8,847,360 px and 8K is 33,177,600 px --- ## Colors  <!-- .element: style="height:400px" --> -- ### RGB Red, Green, Blue  <!-- .element: style="height:400px" --> NOTE: these are called "channels" -- ### Example Values - Red: (255, 0, 0) - Green: (0, 255, 0) - Blue: (0, 0, 255) - White: (255, 255, 255) <!-- .element: class="fragment" --> - Black: (0, 0, 0) <!-- .element: class="fragment" --> -- ### Bits and Bytes - How many bits in a byte? _8_ <!-- .element: class="fragment" --> - How many numbers in a byte? _256_ <!-- .element: class="fragment" --> -- ### Hexadecimal Hexadecimal is a base-16 number system 0 = 0 9 = 9 10 = A 15 = F -- ### Colors in Hex - Red: #FF0000 - Green: #00FF00 - Blue: #0000FF -- ### Transparency - RGBA (Red, Green, Blue, Alpha) - Alpha: 0 = transparent, 255 = opaque - Red (RGBA): (255, 0, 0, 255) - Red (Hex): #FF0000FF --- ## Review  <!-- .element: style="height:400px" --> -- ### Where is the origin? Top-left corner (0, 0) <!-- .element: class="fragment" --> -- ### What is "resolution"? Resolution is the number of pixels in each dimension <!-- .element: class="fragment" --> -- ### What are the primary colors of light? RGB (Red, Green, Blue) <!-- .element: class="fragment" --> -- ### How can you represent white in hex? #FFFFFF <!-- .element: class="fragment" --> -- ### What does the "alpha" channel represent? Transparency <!-- .element: class="fragment" --> --- ## Now for Some Coding... <!-- .element: class="r-fit-text" --> [Intro to Pygame](/2024/fall/computer-science/slides/pygame)
